產品描述

攤鋪機行走鏈軌拖輪主要作用是支撐行走鏈軌和攤鋪機在行走的時候輔助鏈軌運行。

履帶鏈軌的使用時間往往取決于履帶的張緊程度和調節是否合理，因此要常檢查上部履帶的下?lián)隙取z查的方法是：先把履帶清掃干凈，把一木楔放在從動輪后上方，然后開動行走履帶擠壓木楔，這樣履帶接地的下端即被張緊，上部松弛的部分就下?lián)希弥背邷y(cè)量下?lián)隙龋隙纫话闶?8~15)mm。

   履帶張緊裝臵由油缸、張緊橫梁和張緊彈簧組成。張緊的方法是：用高壓油槍將鈣基潤滑脂從注油嘴注入油缸，推動活塞，再通過張緊橫梁推動從動輪移動實現履帶張緊。當需要松弛時，緩慢逆時針方向旋轉注油閥使之松開，潤滑脂將從排油口排出。 注意：如果左右兩側履帶下垂量不同，履帶行走時會跑偏。

免責聲明丨 部分內容來源網絡！本文僅供交流學習 , 版權歸屬原作者，部分圖片、內容推送時未能及時與原作者取得聯系，若來源標注錯誤或侵犯到您的權益煩請告知，我們將立即刪除.

QQ郵箱：2870202745@qq.com

網易郵箱：LS13645201509@163.com

The main function of the walking chain track tugboat of the paver is to support the walking chain track and assist the paver in running the chain track during walking.

The usage time of the track chain track often depends on the tension and reasonable adjustment of the track, so it is necessary to regularly check the lower deflection of the upper track. The method of inspection is to first clean the track, place a wooden wedge above the driven wheel, and then start the walking track to squeeze the wooden wedge. This way, the lower end of the track is tensioned, and the loose part on the upper part is bent down. Measure the deflection with a ruler, and the normal deflection is generally (8-15) mm.

The track tensioning device consists of an oil cylinder, a tensioning crossbeam, and a tensioning spring. The method of tensioning is to use a high-pressure oil gun to inject calcium based grease into the oil cylinder through the oil nozzle, push the piston, and then use the tensioning crossbeam to push the driven wheel to move to achieve track tensioning. When relaxation is needed, slowly rotate the oil filling valve counterclockwise to release it, and the lubricating grease will be discharged from the oil outlet. Attention: If the sag of the left and right tracks is different, the tracks will deviate when walking.

Disclaimer | Part of the content is sourced from the internet! This article is for communication and learning purposes only, and the copyright belongs to the original author. Some images and content were not promptly communicated to the original author. If the source labeling is incorrect or infringes on your rights, please inform us and we will immediately delete it
